Configure System Information
83
M4300 Series and M4300-96X Fully Managed Switches User Manual
Configure Green Ethernet Settings
To configure the Green Ethernet settings:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select System > Management > Green Ethernet > Green Ethernet Configuration.
6. Select the EEE mode Disable or Enable radio button.
The factory default is enable.
Energy Ef
ficient Ethernet (EEE) combines the MAC with a family of PHYs that support
operation in a low power mode. It is defined by IEEE 802.3az Energy Efficient
Task
Force. Lower power mode enables both the send and receive sides of the link to disable
some functionality for power savings when lightly loaded. Transition to low power mode
does not change the link status. Frames in transit are not dropped or corrupted in
transition to and from low power mode. Transition time is transparent to upper layer
protocols and applications.
7. Click the Apply button.
Your settings are saved.
Configure Green Ethernet Interface Settings
To configure the Green Ethernet interface settings:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
