Configure Switching Information
226
M4300 Series and M4300-96X Fully Managed Switches User Manual
6. To refresh the page with the latest information on the switch, click the Update button.
The following table describes the information available on the STP Statistics page.
Configure PVST VLAN Settings
You can view and configure Per VLAN Spanning Tree Protocol (PVST)/Per VLAN Rapid
Spanning Tree Protocol (RPVST) VLAN settings for the device.
To configure PVST/RPVST VLAN settings for the device:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
Table 80. STP Statistics
Field Description
Interface Selects one of the physical or port channel interfaces of the switch.
STP BPDUs Received Number of STP BPDUs received at the selected port.
STP BPDUs Transmitted Number of STP BPDUs transmitted from the selected port.
RSTP BPDUs Received Number of RSTP BPDUs received at the selected port.
RSTP BPDUs Transmitted Number of RSTP BPDUs transmitted from the selected port.
MSTP BPDUs Received Number of MSTP BPDUs received at the selected port.
MSTP BPDUs Transmitted Number of MSTP BPDUs transmitted from the selected port.
