Configure Switching Information
230
M4300 Series and M4300-96X Fully Managed Switches User Manual
Your settings are saved.
The following table describes the nonconfigurable information that the PVST/RPVST
Interface Configuration page displays.
View PVST Statistics
You can view and configure Per VLAN Spanning Tree Protocol (PVST)/Per VLAN Rapid
Spanning Tree Protocol (RPVST) Statistics settings for the device.
 To view the PVST/RPVST statistics:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Switching > STP >
Advanced > PVST Statistics.
Table 83. PVST/RPVST Interface Configuration
Field Description
Interface The list of physical interfaces and LAGs.
Role Indicates the role of the interface. Possible values are as follows:
Disabled, Root, Designated, Alternate, Backup, and Master
.
Note: The blank field is displayed for the interface which is
not included for the specified VLAN.
Status Indicates the status of the interface. Possible values are as follows:
Discarding, Learning, Forwarding, and Disabled.
Note: The blank field is displayed for the interface which is
not included for the specified VLAN.

NETGEAR M4300 Specifications

General

Model	M4300
Form Factor	Rack-Mountable
Layer	Layer 3
Stackable	Yes
Managed	Yes
Memory	Varies by model
Flash Memory	Varies by model
Warranty	Lifetime
Ports	Varies by model (24 or 48 ports)
PoE	Available on some models
Port Speed	10/100/1000 Mbps, 10Gbps on uplinks
Forwarding Rate	Varies by model
Jumbo Frame Support	Yes
VLAN Support	Yes
Quality of Service (QoS)	Yes
Security Features	ACLs, 802.1X
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0° to 50° C (32° to 122° F)
Power Supply	Internal
Uplink Ports	Varies by model (SFP/SFP+ or 10G SFP+)
