Routing
319
M4300 Series and M4300-96X Fully Managed Switches User Manual
6. In the Routes Displayed field, select which routes to display from the following list:
• All Routes. Show all active IPv6 routes.
• Best Routes Only. Show only the best active routes.
• Configured Routes Only. Show the routes configured by the user.
7. To refresh the page with the latest information on the switch, click the Update
button.
The following table describes the nonconfigurable information that is displayed.
IPv6 Route Preferences
Use this page to configure the default preference for each protocol. These values are
arbitrary values in the range of 1 to 255 and are independent of route metrics. Most routing
protocols use a route metric to determine the shortest path known to the protocol,
independent of any other protocol. The best route to a destination is chosen by selecting the
route with the lowest preference value. When there are multiple routes to a destination, the
preference values are used to determine the preferred route. If there is still a tie, the route
with the best route metric is chosen. To avoid problems with mismatched metrics you must
configure different preference values for each of the protocols.
Table 115. IPv6 Advanced Route Table
Field Description
Number of Routes The total number of active routes in the route table.
IPv6 Prefix The network prefix for the active route.
Prefix Length The prefix length for the active route.
Protocol The type of protocol for the active route.
Next Hop Interface The interface over which the route is active. For a reject route, the next
hop would be a Null0 interface.
Next Hop IP Address The next hop IPv6 address for the active route.
Preference The route preference of the configured route.
