Page #175 background imageLoading...
Page #175 background image
Stacking
175
M4300 Series and M4300-96X Fully Managed Switches User Manual
View NSF Checkpoint Statistics
To view NSF checkpoint statistics:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select System > Chassis > NSF > Checkpoint Statistics.
6. T
o reset the statistics on the page, click the Clear
button.
Restart In Progress Indicates whether a restart is in progress. A restart is not considered
complete until all hardware tables are fully reconciled.
Warm Restart Ready Indicates whether the initial full checkpoint finished.
Copy of Running Configuration to Backup Unit
Status Status of copying the running configuration to backup blades.
Backup Configuration Age Indicates the time since the running configuration was last copied to the
backup blade.
Time Until Next Backup Indicates the number of seconds until the running configuration is copied to
the backup blade.
NSF Support on Unit
Unit ID The slot number for the blade.
NSF Support Displays whether the switch supports the nonstop forwarding (NSF)
feature.
Table 63. NSF Summary (continued)
Field Description
