NETGEAR M4300 User Manual

Manage Device Security
574
M4300 Series and M4300-96X Fully Managed Switches User Manual
6. From the ACL Name menu, select the DAI ARP ACL for which you want to configure the
rule.
7. In the Source IP Address
field, enter the source IP address that must be used as a match
for the rule.
8. In the Source MAC Address
field, enter the source MAC address that must be used as a
match for the rule.
9. Click the Add button.
The rule is added to the selected ACL.
View DAI Statistics
 To view the DAI statistics:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Security > Control > Dynamic
ARP Inspection > DAI Statistics
.
6. To refresh the page with the latest information on the switch, click the Update
button.
7. To clear the DAI statistics, click the Clear button.
The following table describes the nonconfigurable information displayed on the page.
Table 208. DAI Statistics
Field Description
VLAN The enabled VLAN ID for which statistics are to be displayed.
DHCP Drops Number of ARP packets that were dropped by DAI because there is no
matching DHCP snooping binding entry found.

NETGEAR M4300 Specifications

General

Model	M4300
Form Factor	Rack-Mountable
Layer	Layer 3
Stackable	Yes
Managed	Yes
Memory	Varies by model
Flash Memory	Varies by model
Warranty	Lifetime
Ports	Varies by model (24 or 48 ports)
PoE	Available on some models
Port Speed	10/100/1000 Mbps, 10Gbps on uplinks
Forwarding Rate	Varies by model
Jumbo Frame Support	Yes
VLAN Support	Yes
Quality of Service (QoS)	Yes
Security Features	ACLs, 802.1X
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0° to 50° C (32° to 122° F)
Power Supply	Internal
Uplink Ports	Varies by model (SFP/SFP+ or 10G SFP+)
