Multicast Routing
441
M4300 Series and M4300-96X Fully Managed Switches User Manual
This sets the administrative status of PIM-SM in the router. The default is Disable.
8. In the Hello Interval field, enter the time in seconds between the transmission of PIM hello
messages on this interface.
The valid values are from 0 to 18000. The default value is 30.
9. In the Join/Prune Interval field, enter the frequency at which PIM Join/Prune messages are
transmitted on this PIM interface.
The valid values are from 0 to 18000. The default value is 60.
10. In the BSR Border field, select the Enable or Disable option to set the bootstrap router
(BSR) border status on the selected interface.
11. Enter the DR Priority for the selected interface.
The valid values are from 0 to 2147483647. The default value is 1.
12. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable information that is displayed.
View the IPv6 PIM Neighbor
To view the IPv6 PIM neighbor:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Routing> IPv6 Multicast > IPv6 PIM > PIM Neighbor.
Table 169. IPv6 PIM Interface Configuration
Field Description
Protocol State The state of PIM in the router. either Operational or Non-Operational.
IPv6 Prefix/Length The IPv6 address prefix and the length of the selected interface.
Designated Router The designated router on the selected PIM interface.
Neighbor Count The number of PIM neighbors on the selected interface.
