Configure System Information
123
M4300 Series and M4300-96X Fully Managed Switches User Manual
Configure PoE Power Settings
To configure PoE power settings:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
Class The Class defines the range of power a PD is drawing from the system.
Class definitions:
0 – 0.44-12.95 (watts)
1 – 0.44-3.83 (watts)
2 – 0.44-6.48 (watts)
3 – 0.44-12.95 (watts)
4 – 0.44-25.5 (watts)
Output Voltage Current voltage being delivered to device in volts.
Output Current Current being delivered to device in mA.
Output Power Current power being delivered to device in Watts.
Status The status is the operational status of the port PD detection.
• Disabled. No power being delivered.
• DeliveringPower. Power is being drawn by device.
• Fault. Indicates a problem with the port.
• T
est.
The port is in test mode.
• otherFault. The port is idle due to error condition.
• Searching. The port is not in one of the above states.
Fault Status Describes the error description when the PSE port is in fault status.
• No Error.
The PSE port is not in any error state.
• MPS Absent
. The PSE port has detected an absence of main
power supply
.
• Short.
The PSE port has detected a short circuit condition.
• Overload.The PD connected to the PSE port tried to provide more
power than it is permissible by the hardware.
• Power Denied.
The PSE port was denied power because of
shortage of power or due to administrative action.
Table 43. Nonconfigurable fields on the Advanced PoE Configuration page (continued)
Field Description
