NETGEAR M4300 User Manual

Monitor the System
650
M4300 Series and M4300-96X Fully Managed Switches User Manual
The following table describes the nonconfigurable information.
Configure sFlow Agent Advanced Settings
 To configure sFlow agent advanced settings:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Monitoring> sFlow >
Advanced > sFlow
Agent Information.
6. In the Source Interface list, select the management interface to be used for sFlow Agent.
Possible values are as follows:
• None
• Routing interface
Table 224. sFlow Basic Agent Information
Field Description
Agent Version Uniquely identifies the version and implementation of this MIB. The version
string must use the following structure: MIB Version;Organization;Software
Revision where:
• MIB V
ersion: For example, 1.3, the version of this MIB
• Organization: NETGEAR, Inc.
• Revision: 1.0
Agent Address The IP address associated with this agent.

NETGEAR M4300 Specifications

General

Model	M4300
Form Factor	Rack-Mountable
Layer	Layer 3
Stackable	Yes
Managed	Yes
Memory	Varies by model
Flash Memory	Varies by model
Warranty	Lifetime
Ports	Varies by model (24 or 48 ports)
PoE	Available on some models
Port Speed	10/100/1000 Mbps, 10Gbps on uplinks
Forwarding Rate	Varies by model
Jumbo Frame Support	Yes
VLAN Support	Yes
Quality of Service (QoS)	Yes
Security Features	ACLs, 802.1X
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0° to 50° C (32° to 122° F)
Power Supply	Internal
Uplink Ports	Varies by model (SFP/SFP+ or 10G SFP+)
