NETGEAR M4300 User Manual

Multicast Routing
423
M4300 Series and M4300-96X Fully Managed Switches User Manual
Configure the IGMP Proxy Interface
 To configure the IGMP proxy interface:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Routing> Multicast > IGMP > Proxy Interface Configuration.
6. Use the Interface list to select the port.
At least one router interface must be configured before you configure or display data for
an IGMP proxy interface, and it must not be an IGMP routing interface.
Source Filter Mode The source filter mode (Include, Exclude, or NA) for the specified
group on this interface. When NA mode is active, the field is blank.
Source Hosts This parameter shows source addresses that are members of this
multicast address.
Expiry Time This parameter shows expiry time interval against each source address
that are members of this multicast group.
This is the amount of time
after which the specified source entry is aged out.
Table 159. Multicast IGMP Membership (continued)
Field Description

NETGEAR M4300 Specifications

General

Model	M4300
Form Factor	Rack-Mountable
Layer	Layer 3
Stackable	Yes
Managed	Yes
Memory	Varies by model
Flash Memory	Varies by model
Warranty	Lifetime
Ports	Varies by model (24 or 48 ports)
PoE	Available on some models
Port Speed	10/100/1000 Mbps, 10Gbps on uplinks
Forwarding Rate	Varies by model
Jumbo Frame Support	Yes
VLAN Support	Yes
Quality of Service (QoS)	Yes
Security Features	ACLs, 802.1X
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0° to 50° C (32° to 122° F)
Power Supply	Internal
Uplink Ports	Varies by model (SFP/SFP+ or 10G SFP+)
