NETGEAR M4300 User Manual

Manage Device Security
596
M4300 Series and M4300-96X Fully Managed Switches User Manual
The following table describes the information that is displayed in the Interface Binding
Status section.
View and Delete MAC ACL Bindings in the MAC Binding Table
You can view and delete the MAC ACL bindings in the MAC Binding Table.
 To view and delete MAC ACL bindings:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Security >
ACL > Basic > MAC Binding T
able.
6. To delete a MAC ACL-to-interface binding, select the check box next to the interface and
click the Delete
button.
Table 212. Interface Binding Status
Field Description
Interface The interface of the ACL assigned.
Direction Displays selected packet filtering direction for ACL.
ACL Type The type of ACL assigned to selected interface and direction.
ACL ID The ACL number (in case of IP ACL) or ACL name (in case of MAC
ACL) identifying the
ACL assigned to selected interface and direction.
Sequence Number The sequence number signifying the order of the specified
ACL relative
to other ACLs assigned to selected interface and direction.
