Page #260 background imageLoading...
Page #260 background image
Configure Switching Information
260
M4300 Series and M4300-96X Fully Managed Switches User Manual
6. Use Search By to search for MAC addresses by MAC address, VLAN ID, or port:
Searched by MAC Address. Select
MAC Address, enter the 6-byte hexadecimal
MAC address in two-digit groups separated by colons, for example,
01:23:45:67:89:AB. Then click the Go button. If the address exists, that entry is
displayed as the first entry followed by the remaining (greater) MAC addresses. An
exact match is required.
Searched by VLAN ID. Select VLAN ID, enter the VLAN ID, for example, 100.
Then
click the
Go button. If the address exists, the entry is displayed as the first entry
followed by the remaining (greater) MAC addresses.
Searched by Port. Select Port, enter the port ID in Unit/Slot/Port format, for example,
2/1/1. Then click
the Go button. If the address exists, the entry is displayed as the first
entry followed by the remaining (greater) MAC addresses.
The following table describes the nonconfigurable information displayed on the page.
Set the Dynamic Address Aging Interval
You can set the address aging interval for the specified forwarding database.
To set the address aging interval:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
Table 94. Basic Address Table
Field Description
Total MAC Address Displaying the number of total MAC addresses learned or configured.
MAC Address A unicast MAC address for which the switch has forwarding and/or
filtering information. The format is a 6 byte MAC address that is
separated by colons, for example 01:23:45:67:89:AB.
VLAN ID The VLAN ID associated with the MAC address.
Port The port upon which this address was learned.
Status The status of this entry
. The meanings of the values are as follows:
Static.
The value of the corresponding instance was added by the
system or a user and cannot be relearned.
Learned.
The value of the corresponding instance was learned,
and is being used.
Management. The
value
of the corresponding instance is also the
value of an existing instance of dot1dStaticAddress.
