Monitor the System
651
M4300 Series and M4300-96X Fully Managed Switches User Manual
• Routing VLAN
• Routing loopback interface
• T
unnel interface
• Service port
By default, VLAN 1 is used as the source interface.
7. Click the Apply
button.
Your settings are saved.
The following table describes the nonconfigurable information.
Configure an sFlow Receiver
Use the sFlow Receiver Configuration page to configure the sFlow Receiver.
 To configure an sFlow receiver:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Monitoring> sFlow >
Advanced > sFlow Receiver Configuration.
Table 225. sFlow Advanced Agent Information
Field Description
Agent Version Uniquely identifies the version and implementation of this MIB. The version
string must use the following structure: MIB Version;Organization;Software
Revision where:
• MIB V
ersion: '1.3', the version of this MIB
• Organization: NETGEAR, Inc.
• Revision: 1.0
Agent Address The IP address associated with this agent.
