NETGEAR M4300 User Manual

Multicast Routing
454
M4300 Series and M4300-96X Fully Managed Switches User Manual
The following table describes the nonconfigurable information that is displayed.
View the IPv6 MLD Proxy Membership
 To view the IPv6 multicast MLD proxy membership:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Routing> IPv6 Multicast > MLD > Proxy Membership.
6. T
o refresh the page with the latest information on the switch, click the Update
button.
Table 177. IPv6 Multicast MLD Proxy Interface Statistics
Field Description
Proxy Interface The interface on which MLD proxy packets received.
Version The version of MLD proxy packets received.
Queries Received The number of MLD proxy queries received.
Reports Received The number of MLD proxy reports received.
Reports Sent The number of MLD proxy reports sent.
Leaves Received The number of MLD proxy leaves received.
Leaves Sent The number of MLD proxy leaves sent.

NETGEAR M4300 Specifications

General

Model	M4300
Form Factor	Rack-Mountable
Layer	Layer 3
Stackable	Yes
Managed	Yes
Memory	Varies by model
Flash Memory	Varies by model
Warranty	Lifetime
Ports	Varies by model (24 or 48 ports)
PoE	Available on some models
Port Speed	10/100/1000 Mbps, 10Gbps on uplinks
Forwarding Rate	Varies by model
Jumbo Frame Support	Yes
VLAN Support	Yes
Quality of Service (QoS)	Yes
Security Features	ACLs, 802.1X
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0° to 50° C (32° to 122° F)
Power Supply	Internal
Uplink Ports	Varies by model (SFP/SFP+ or 10G SFP+)
