Configure Switching Information
232
M4300 Series and M4300-96X Fully Managed Switches User Manual
6. Use Search by MAC Address to enter a MAC address.
Enter six two-digit hexadecimal numbers separated by colons, for example
00:01:23:43:45:67.
7. Click the GO button.
If the address exists, that entry is displayed. An exact match is required.
View the MFDB Statistics
 To view the MFDB statistics:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
Table 84. MFDB Table
Field Description
MAC Address The multicast MAC address for which you requested data.
VLAN ID The VLAN ID to which the multicast MAC address is related.
Type This displays the type of the entry. Static entries are those that are
configured by the end user
. Dynamic entries are added to the table as a
result of a learning process or protocol.
Component This is the component that is responsible for this entry in the Multicast
Forwarding Database. Possible values are IGMP snooping, GMRP
,
Static Filtering and MLD snooping.
Description The text description of this multicast table entry
. Possible values are
Management Configured, Network Configured and Network
Assisted.
Forwarding Interfaces The resultant forwarding list is derived from combining all the
forwarding interfaces and removing the interfaces that are listed as the
static filtering interfaces.
