NETGEAR M4300 User Manual

Configure System Information
90
M4300 Series and M4300-96X Fully Managed Switches User Manual
The following table describes the nonconfigurable fields.
Configure the Green Ethernet EEE LPI History
 To configure the port Green Mode EEE history:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select System
 Management  Green Ethernet  Green Ethernet LPI History.
Table 31. Green Ethernet Interface Summary
Field Description
Interface Interface for which data is displayed or configured.
EEE Admin mode Enable or disable Energy Efficient Ethernet mode on the port. When
EEE mode is enabled, the port transitions to Low Power mode during
Link Idle condition. If EEE Admin Mode is not supported, then N/A is
displayed.

NETGEAR M4300 Specifications

General

Model	M4300
Form Factor	Rack-Mountable
Layer	Layer 3
Stackable	Yes
Managed	Yes
Memory	Varies by model
Flash Memory	Varies by model
Warranty	Lifetime
Ports	Varies by model (24 or 48 ports)
PoE	Available on some models
Port Speed	10/100/1000 Mbps, 10Gbps on uplinks
Forwarding Rate	Varies by model
Jumbo Frame Support	Yes
VLAN Support	Yes
Quality of Service (QoS)	Yes
Security Features	ACLs, 802.1X
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0° to 50° C (32° to 122° F)
Power Supply	Internal
Uplink Ports	Varies by model (SFP/SFP+ or 10G SFP+)
