NETGEAR M4300 User Manual

Configure Switching Information
270
M4300 Series and M4300-96X Fully Managed Switches User Manual
13. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable information displayed on the page.
Configure LAG Membership
You can select two or more full-duplex Ethernet links to be aggregated together to form a link
aggregation group (LAG), which is also known as a port-channel. The switch can treat the
port-channel as if it were a single link.
 To configure LAG membership:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Switching> LAG > LAG Membership.
Table 98. LAG Configuration
Field Description
LAG Description Enter the description string to be attached to a LAG. It can be up to 64
characters in length.
LAG ID Identification of the LAG.
LAG State Indicates whether the link is up or down.
Configured Ports Indicate the ports that are members of this port-channel
Active Ports Indicates the ports that are actively participating in the port-channel.

NETGEAR M4300 Specifications

General

Model	M4300
Form Factor	Rack-Mountable
Layer	Layer 3
Stackable	Yes
Managed	Yes
Memory	Varies by model
Flash Memory	Varies by model
Warranty	Lifetime
Ports	Varies by model (24 or 48 ports)
PoE	Available on some models
Port Speed	10/100/1000 Mbps, 10Gbps on uplinks
Forwarding Rate	Varies by model
Jumbo Frame Support	Yes
VLAN Support	Yes
Quality of Service (QoS)	Yes
Security Features	ACLs, 802.1X
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0° to 50° C (32° to 122° F)
Power Supply	Internal
Uplink Ports	Varies by model (SFP/SFP+ or 10G SFP+)
