6. Use the Search menu to search for multicast entries by interface or group:
• Select Interface from the menu, enter the interface in unit/slot/port format (for
example 1/0/13), and click the Go button.
If the entry exists, the entry is displayed as the first entry
, followed by the remaining
entries.
• Select Group from the menu, enter the multicast group IP address, and click the Go
button.
If the entry exists, that entry with the matching group is displayed as the first entry,
followed by the remaining entries. An exact match is required.
7. To refresh the page with the latest information on the switch, click the Update button.
The following table describes the nonconfigurable information that is displayed.
Table 158. Multicast IGMP Groups
Field Description
Interface The interface for which data is to be displayed.
Multicast Group IP The IP multicast group address for which data is to be displayed.
Last Reporter The IP address of the source of the last membership report received for
the IP multicast group address on the selected interface.
Up Time The time elapsed since this entry was created.
Expiry Time The minimum amount of time remaining before this entry is aged out.
Version 1 Host Timer The time remaining until the local router assumes that no IGMP version
1 members are on the IP subnet attached to this interface. When an
IGMPv1 membership report is received, this timer is reset to the group
membership timer
. While this timer is non-zero, the local router ignores
any IGMPv2 leave messages for this group that it receives on the
selected interface.
This field is displayed only if the interface is
configured for IGMP version 1.
Version 2 Host Timer The time remaining until the local router assumes that no IGMP version
2 members are on the IP subnet attached to this interface. When an
IGMPv2 membership report is received, this timer is reset to the group
membership timer
. While this timer is non-zero, the local router ignores
any IGMPv1 and IGMPv3 leave messages for this group that it receives
on the selected interface.
This field is displayed only if the interface is
configured for IGMP version 2.
Compatibility This parameter shows group compatibility mode (v1, v2, and v3) for this
group on the specified interface.
Filter Mode The source filter mode (Include, Exclude, or NA) for the specified
group on this interface. When NA mode is active, the field is blank.
