Sharp LH79524 - Table 4-3. Frame Buffer Pixel Storage Format [15:0]

LH79524/LH79525 User’s Guide Color Liquid Crystal Display Controller
Version 1.0 4-7
NOTES:
1. LH79525 with 12-Bit CLCDC
2. LH79524 with 16-Bit CLCDC
Table 4-3. Frame Buffer Pixel Storage Format [15:0]
BPP DMA FIFO OUTPUT BITS
1
1514131211109876543210
p15 p14 p13 p12 p11 p10 p9 p8 p7 p6 p5 p4 p3 p2 p1 p0
2
p7 p6 p5 p4 p3 p2 p1 p0
1010101010101010
4
p3 p2 p1 p0
3210321032103210
8
p1 p0
7654321076543210
12
1
p0
1110 9 8 7654 3210
16
2
p0
1514131211109876543210
