Color Liquid Crystal Display Controller LH79524/LH79525 User’s Guide
4-12 Version 1.0
4.3.7 LCD Data Multiplexing
When LCD data is written to a LCD panel, the manner in which the LCD data is multiplexed
onto the external data bus varies for STN, TFT, AD-TFT, or HR-TFT panels. Table 4-10
and Table 4-11 show the data multiplexing for each supported panel.
NOTES:
‘X’ is Don’t Care.
‘MLSTNx’ = Mono Lower panel STN data bit ‘x’
‘MUSTNx’ = Mono Upper panel STN data bit ‘x’
‘CLSTNx’ = Color Lower panel STN data bit ‘x’
‘CUSTNx’ = Color Upper panel STN data bit ‘x’
Table 4-10. LH79524 LCD Data Multiplexing
CABGA
BALL
NO.
CABGA
BALL
NAME
STN TFT
MONO 4-BIT MONO 8-BIT COLOR COLOR
SINGLE
PANEL
DUAL
PANEL
SINGLE
PANEL
DUAL
PANEL
SINGLE
PANEL
DUAL
PANEL
SINGLE
PANEL
C2 LCDVD15 MUSTN0 MUSTN0 MUSTN0 MUSTN0 CUSTN0 CUSTN0 INTENSITY
C1 LCDVD14 X X X MLSTN4 X CLSTN4 BLUE4
C10 LCDVD13 X X MUSTN6 MUSTN6 CUSTN6 CUSTN6 BLUE3
A10 LCDVD12 X X X MLSTN7 X CLSTN7 BLUE2
A11 LCDVD11 X X X MLSTN6 X CLSTN6 BLUE1
B10 LCDVD10 X X X MLSTN5 X CLSTN5 BLUE0
C9 LCDVD9 X MLSTN3 X MLSTN3 X CLSTN3 GREEN4
B9 LCDVD8 X MLSTN2 X MLSTN2 X CLSTN2 GREEN3
A9 LCDVD7 X MLSTN1 X MLSTN1 X CLSTN1 GREEN2
A8 LCDVD6 X MLSTN0 X MLSTN0 X CLSTN0 GREEN1
B8 LCDVD5 X X MUSTN7 MUSTN7 CUSTN7 CUSTN7 GREEN0
C8 LCDVD4 X X MUSTN5 MUSTN5 CUSTN5 CUSTN5 RED4
A7 LCDVD3 X X MUSTN4 MUSTN4 CUSTN4 CUSTN4 RED3
B7 LCDVD2 MUSTN3 MUSTN3 MUSTN3 MUSTN3 CUSTN3 CUSTN3 RED2
C7 LCDVD1 MUSTN2 MUSTN2 MUSTN2 MUSTN2 CUSTN2 CUSTN2 RED1
A6 LCDVD0 MUSTN1 MUSTN1 MUSTN1 MUSTN1 CUSTN1 CUSTN1 RED0
