LH79524/LH79525 User’s Guide Vectored Interrupt Controller
Version 1.0 18-11
18.2.2.8 Software Interrupt Clear Register (SOFTINTCLEAR)
This Write Only register clears the corresponding bit (and the interrupt assertion) in the
SOFTINT Register. Bits [31:0] correspond to the interrupt number in Table 18-1
.
Table 18-17. SOFTINTCLEAR Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD SoftInt Clear
RESET 0000000000000000
RW WO WO WO WO WO WO WO WO WO WO WO WO WO WO WO WO
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD SoftInt Clear
RESET 0000000000000000
RW WO WO WO WO WO WO WO WO WO WO WO WO WO WO WO WO
ADDR 0xFFFFF000 + 0x01C
Table 18-18. SOFTINTCLEAR FIelds
BITS NAME DESCRIPTION
31:0 SoftInt Clear
Clear SoftInt Register Bits Clears bits in the SOFTINT Register.
For each bit:
1 = Clears the corresponding bit in the SoftInt Register
0 = Has no effect
