LH79524/LH79525 User’s Guide Timers
Version 1.0 15-19
15.2.2.11 Timer 1 Counter Register (CNT1)
The CNT1 Register is a 16-bit, Read/Write up counter. The counter can be read or written
to while it is operating. As a result, counts can be read at any time or the current count can
be changed.
Table 15-24. CNT1 Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD ///
RESET 0000000000000000
RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD TM1CNT
RESET 0000000000000000
RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
ADDR 0xFFFC4000 + 0x3C
Table 15-25. CNT1 Register Definitions
BITS NAME DESCRIPTION
31:16 ///
Reserved Reading this field returns 0. Write the reset value.
15:0 TM1CNT Timer 1 Count 16-bit up counter value.
