11.2.2.31 Resistor Configuration Control 22 Register (RESCTL22)
The RESCTL22 Register allows software to configure a number of the LH79524/LH79525
pull-up/pull-down resistors.
Table 11-62. RESCTL22 Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD ///
RESET 0000000000000000
RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD PF1 PF0 PG7 PG6 PG5 PG4 PG3 PG2
RESET 0101010101010101
RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
ADDR 0xFFFE5000 + 0xAC
Table 11-63. RESCTL22 Fields
BIT NAME DESCRIPTION
31:16 /// Reserved Reading returns 0. Write the reset value.
15:14 PF1
Pin PF1/LCDVD7 Resistor Assignment
00 = No Pull-Down or Pull-Up
01 = Pull-Down
10 = Pull-Up
11 = Reserved
13:12 PF0
Pin PF0/LCDVD6 Resistor Assignment
00 = No Pull-Down or Pull-Up
01 = Pull-Down
10 = Pull-Up
11 = Reserved
11:10 PG7
Pin PG7/LCDVD5 Resistor Assignment
00 = No Pull-Down or Pull-Up
01 = Pull-Down
10 = Pull-Up
11 = Reserved
9:8 PG6
Pin PG6/LCDVD4 Resistor Assignment
00 = No Pull-Down or Pull-Up
01 = Pull-Down
10 = Pull-Up
11 = Reserved
7:6 PG5
Pin PG5/LCDVD3 Resistor Assignment
00 = No Pull-Down or Pull-Up
01 = Pull-Down
10 = Pull-Up
11 = Reserved
