LH79524/LH79525 User’s Guide Reset, Clock, and Power Controller
Version 1.0 13-29
13.2.2.19 External Interrupt Configuration Register (INTCONFIG)
This register configures the individual external interrupts to be either edge-sensitive or
level-sensitive, and either active HIGH or active LOW. Following reset, all bits are 0 and
configure the external interrupts to be active LOW, level sensitive.
The corresponding edge-trigger interrupt should be cleared before enabling the edge-
trigger interrupt to avoid a false interrupt.
Table 13-46. INTCONFIG Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD ///
RESET 0000000000000000
RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD INT7 INT6 INT5 INT4 INT3 INT2 INT1 INT0
RESET 0000000000000000
RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
ADDR 0xFFFE2000 + 0x80
Table 13-47. INTCONFIG Fields
BITS NAME DESCRIPTION
31:16 /// Reserved Reading returns 0. Write the reset value.
15:14 INT7
Configures External Interrupt INT7
00 = Configures INT7 to be a LOW, level trigger.
01 = Configures INT7 to be a HIGH, level trigger.
10 = Configures INT7 to be a falling-edge trigger.
11 = Configures INT7 to be a rising-edge trigger.
13:12 INT6
Configures External Interrupt INT6
00 = Configures INT6 to be a LOW, level trigger.
01 = Configures INT6 to be a HIGH, level trigger.
10 = Configures INT6 to be a falling-edge trigger.
11 = Configures INT6 to be a rising-edge trigger.
11:10 INT5
Configures External Interrupt INT5
00 = Configures INT5 to be a LOW, level trigger.
01 = Configures INT5 to be a HIGH, level trigger.
10 = Configures INT5 to be a falling-edge trigger.
11 = Configures INT5 to be a rising-edge trigger.
9:8 INT4
Configures External Interrupt INT4
00 = Configures INT4 to be a LOW, level trigger.
01 = Configures INT4 to be a HIGH, level trigger.
10 = Configures INT4 to be a falling-edge trigger.
11 = Configures INT4 to be a rising-edge trigger.
