7:6 INT3
Configures External Interrupt INT3
00 = Configures INT3 to be a level trigger, active LOW.
01 = Configures INT3 to be a level trigger, active HIGH.
10 = Configures INT3 to be a falling-edge trigger.
11 = Configures INT3 to be a rising-edge trigger.
5:4 INT2
Configures External Interrupt INT2
00 = Configures INT2 to be a level trigger, active LOW.
01 = Configures INT2 to be a level trigger, active HIGH.
10 = Configures INT2 to be a falling-edge trigger.
11 = Configures INT2 to be a rising-edge trigger.
3:2 INT1
Configures External Interrupt INT1
00 = Configures INT1 to be a level trigger, active LOW.
01 = Configures INT1 to be a level trigger, active HIGH.
10 = Configures INT1 to be a falling-edge trigger.
11 = Configures INT1 to be a rising-edge trigger.
1:0 INT0
Configures External Interrupt INT0
00 = Configures INT0 to be a level trigger, active LOW.
01 = Configures INT0 to be a level trigger, active HIGH.
10 = Configures INT0 to be a falling-edge trigger.
11 = Configures INT0 to be a rising-edge trigger.
Table 13-47. INTCONFIG Fields
BITS NAME DESCRIPTION
