Universal Serial Bus Device LH79524/LH79525 User’s Guide
17-16 Version 1.0
17.2.2.7 OUT Interrupt Enable Register (OIE)
OIE provides interrupt enable bits for the interrupts in OIR. Following reset, all interrupts
are enabled.
Table 17-16. OIE Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD ///
RESET 0000000000000000
RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD ///
EP2OUTEN EP1OUTEN
///
RESET 0000000000000110
TYPE RO RO RO RO RO RO RO RO RO RO RO RO RO RW RW RW
ADDR 0xFFFF5000 + 0x024
Table 17-17. OIE Fields
BITS NAME FUNCTION
31:3
/// Reserved Reading returns 0. Write the reset value.
2 EP2OUTEN
Endpoint 2 OUT Interrupt Enable.
0 = Interrupt disabled
1 = Interrupt enabled
1 EP1OUTEN
Endpoint 1 OUT Interrupt Enable.
0 = Interrupt disabled
1 = Interrupt enabled
0
/// Reserved Reading returns 0. Write the reset value.
