Timers LH79524/LH79525 User’s Guide
15-28 Version 1.0
15.2.2.19 Timer 2 Capture Registers (T2CAPn)
There are two T2CAPn Registers for Timer 2. They are designated:
• T2CAPA
• T2CAPB
Each register is a 16-bit, Read Only register. When a capture condition occurs, the con-
tents of the counter CNT2 are stored into the associated Capture Register. Capture Reg-
isters correspond to the input signals CTCAP2A through CTCAP2B, respectively. The
edge of the input signal used to trigger the capturing operation is determined by program-
ming the CTRL Register.
Table 15-40. T2CAPn Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD ///
RESET 0000000000000000
RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD CAPTURE2
RESET 0000000000000000
RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
ADDR
T2CAPA: xFFFC4000 + 0x68
T2CAPB: xFFFC4000 + 0x6C
Table 15-41. T2CAPn Register Definitions
BITS NAME DESCRIPTION
31:16 ///
Reserved Reading this field returns 0. Write the reset value.
15:0 CAPTURE2 Timer 2 Capture 16-bit Capture Register Value.
