Reset, Clock, and Power Controller LH79524/LH79525 User’s Guide

13-24 Version 1.0

13.2.2.14 Silicon Revision Register (SILICONREV)

The SILICONREV register is used in conjunction with the CHIPID register to provide

the SoC part number (CHIPID:PARTNO) and the revision number of the silicon

(SILICONREV:REVNO).

Table 13-32. SILICONREV Register

BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

FIELD ///

RESET 0000000000000000

RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO

BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

FIELD REVNO

RESET 0000000000000010

RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO

ADDR 0xFFFE2000 + 0x3C

Table 13-33. SILICONREV Fields

BITS NAME DESCRIPTION

31:16 /// Reserved Reading returns 0. Do not write.

15:0 REVNO

Revision Number The revision number read from this field corresponds to

the values below.

0x0 = Undefined

0x1 = Revision A.0

0x2 = Revision A.1
