LH79524/LH79525 User’s Guide I

S Converter

Version 1.0 10-13

10.2 Register Reference

This section describes the registers used in I

S Converter.

10.2.1 Memory Map

The base address for the I

S Converter is 0xFFFC8000.

Locations at offsets 0x018 through 0xFFF are reserved and must not be used during

normal operation. Table 10-1 shows the memory mapping.

Table 10-1. I

S Converter Register Summary

ADDRESS

OFFSET

NAME DESCRIPTION

0x000 CTRL Control Register

0x004 STAT Status Register

0x008 IMSC Interrupt Mask Set and Clear Register.

0x00C RIS Raw Interrupt Status register

0x010 MIS Masked Interrupt Status Register

0x014 ICR Interrupt Clear Register

0x018 - 0xFFF /// Reserved — Do not access
