LH79524/LH79525 User’s Guide I/O Configuration

Version 1.0 11-33

11.2.2.23 Resistor Configuration Control 17 Register (RESCTL17)

The RESCTL17 Register allows software to configure a number of the LH79524/LH79525

pull-up/pull-down resistors.

Table 11-46. RESCTL17 Register

BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

FIELD ///

RESET 0000000000000000

RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO

BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

FIELD /// SDCLK

RESET 0000000000000001

RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RW RW

ADDR 0xFFFE5000 + 0x84

Table 11-47. RESCTL17 Fields

BIT NAME DESCRIPTION

31:2 /// Reserved Reading returns 0. Write the reset value.

1:0 SDCLK

Pin SDCLK Resistor Assignment

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved
