15.2.2.17 Timer 2 Counter Register (CNT2)
The CNT2 Register is a 16-bit, read/write up counter. The counter can be read or written
to while it is operating. As a result, counts can be read at any time or the current count can
be changed.
Table 15-36. CNT2 Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD ///
RESET 0000000000000000
RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD TM2CNT
RESET 0000000000000000
RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
ADDR 0xFFFC4000 + 0x5C
Table 15-37. CNT2 Register Definitions
BITS NAME DESCRIPTION
31:16 /// Reserved Reading this field returns 0. Write the reset value.
15:0 TM2CNT Timer 2 Counter 16-bit up-counter value.
