Sharp LH79524 - Table 1-10. AHB Memory Map on Power-Up When Boot Configuration = 0 Bx1 Xx; Table 1-11. Primary AHB Peripheral Register Mapping

LH79524/LH79525 User’s Guide Overview
Version 1.0 1-15
NOTE: *An access to this area will cause a memory abort.
NOTE: *An access to this area will cause a memory abort.
Table 1-10. AHB Memory Map on Power-up when Boot Configuration = 0bX1XX
ADDRESS REMAP = 00
0x00000000 - 0x1FFFFFFF Boot ROM
0x20000000 - 0x2FFFFFFF SDRAM nDCS0
0x30000000 - 0x3FFFFFFF SDRAM nDCS1
0x40000000 - 0x43FFFFFF Static Memory nCS0
0x44000000 - 0x47FFFFFF Boot ROM
0x48000000 - 0x4BFFFFFF Static Memory nCS2
0x4C000000 - 0x4FFFFFFF Static Memory nCS3
0x50000000 - 0x5FFFFFFF Invalid Access*
0x60000000 - 0x7FFFFFFF Internal SRAM
0x80000000 - 0x80000FFF Boot ROM
0x80001000 - 0xFFFBFFFF Invalid Access*
Table 1-11. Primary AHB Peripheral Register Mapping
ADDRESS RANGE DEVICE
0xFFFC0000 - 0xFFFE6FFF APB Bridge
0xFFFF7000 - 0xFFFF0FFF Invalid Access*
0xFFFF1000 - 0xFFFF1FFF External Memory Controller
0xFFFF2000 - 0xFFFF3FFF Invalid Access*
0xFFFF4000 - 0xFFFF4FFF Color LCD Controller
0xFFFF5000 - 0xFFFF5FFF USB Device
0xFFFF6000 - 0xFFFFEFFF Invalid Access*
0xFFFFF000 - 0xFFFFFFFF Vectored Interrupt Controller
