17.2.2.3 Interrupt Register for Endpoint 0, 1, 2, and 3 (IIR)
IIR is a read-only register that indicates which of the interrupts for IN Endpoints 1, 2, and
3 are currently active. It also indicates whether the Endpoint 0 (the Control Endpoint) inter-
rupt is currently active. Upon interrupt, software should read each of the three interrupt reg-
isters (IIR, OIR, and UIR), which clears the interrupt bit. The UIR must be the last register
read and cleared.
Table 17-8. IIR Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD ///
RESET 0000000000000000
RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD ///
EP3IN EP2IN EP1IN EP0IN
RESET 0000000000000000
TYPE RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
ADDR 0xFFFF5000 + 0x008
Table 17-9. IIR Fields
BITS NAME FUNCTION
31:4 /// Reserved Reading returns 0. Write the reset value.
3EP3IN
Endpoint3 IN Interrupt The EP3 interrupt is generated for Interrupt IN transfers. This bit
is programmed to 1 by the USB when: IN_PKT_RDY is cleared to 0 by the USB; The FIFO
is flushed by the USB; and USB has issued a STALL response IN token, indicated by
SENT_STALL = 1. Software clears this interrupt by reading this register.
1 = Interrupt IN transfer pending
0 = Interrupt cleared or the above conditions are not met
2EP2IN
Endpoint2 IN Interrupt The EP2 interrupt is generated for Isochronous Interrupt IN transfers.
The USB block programs this bit to 1 when IN_PKT_RDY bit is cleared to 0 by the USB Host,
the FIFO is flushed by the USB Host, and the USB Host has issued a STALL response IN token,
as indicated by SENT_STALL = 1. Software clears this interrupt by reading this register.
1 = Isochronous Interrupt IN transfer pending
0 = Interrupt cleared or the above conditions are not met
1EP1IN
Endpoint1 IN Interrupt The EP1 interrupt is generated for BULK IN transfers. The USB
block programs this bit to 1 when IN_PKT_RDY bit is cleared to 0 by the USB Host, the FIFO
is flushed by the USB Host, and the USB Host has issued a STALL response IN token, as
indicated by SENT_STALL = 1. Software clears this interrupt by reading this register.
1 = BULK IN transfer pending and the above three conditions are met
0 = Interrupt cleared or the above conditions are not met
0EP0IN
Endpoint 0 Interrupt The EP0 interrupt is generated for Control transfers. The EP0 inter-
rupt is programmed to 1 by the USB block when: OUT_PKT_RDY is set to 1 by the USB Host;
IN_PKT_RDY is cleared to 0 by the USB Host; SENT_STALL is set to 1 by the USB Host;
SETUP_END is set to 1 by the USB Host; and DATA_END is cleared to 0 by the USB Host
(Indicates end of control transfer). Software clears this interrupt by reading this register.
1 = EP0 interrupt set
0 = EP0 interrupt cleared or the above conditions are not met
