I/O Configuration LH79524/LH79525 User’s Guide
11-10 Version 1.0
11.2.2.8 Resistor Configuration Control 5 Register (RESCTL5)
The RESCTL5 Register allows software to configure a number of the LH79524/LH79525
pull-up/pull-down resistors
.
Table 11-16. RESCTL5 Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD ///
RESET 0000000000000000
RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD PA1 PA0 PB7 PB6 PB5 PB4 PB3 PB2
RESET 0101010101010110
RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
ADDR 0xFFFE5000 + 0x24
Table 11-17. RESCTL5 Fields
BIT NAME DESCRIPTION
31:16 /// Reserved Reading returns 0. Write the reset value.
15:14 PA1
Pin PA1/INT3/UARTTX2/UARTIRTX2 Resistor Assignment
00 = No Pull-Down or Pull-Up
01 = Pull-Down
10 = Pull-Up
11 = Reserved
13:12 PA0
Pin PA0/INT2/UARTRX2/UARTIRRX2 Resistor Assignment
00 = No Pull-Down or Pull-Up
01 = Pull-Down
10 = Pull-Up
11 = Reserved
11:10 PB7
Pin PB7/INT1/UARTTX0/UARTIRTX0 Resistor Assignment
00 = No Pull-Down or Pull-Up
01 = Pull-Down
10 = Pull-Up
11 = Reserved
9:8 PB6
Pin PB6/INT0/UARTRX0/UARTIRRX0 Resistor Assignment
00 = No Pull-Down or Pull-Up
01 = Pull-Down
10 = Pull-Up
11 = Reserved
7:6 PB5
Pin PB5/SSPTX/UARTTX1/UARTIRTX1 Resistor Assignment
00 = No Pull-Down or Pull-Up
01 = Pull-Down
10 = Pull-Up
11 = Reserved
