Sharp LH79524 - Table 11-18. MUXCTL6 Register; Table 11-19. MUXCTL6 Fields; Multiplexing Control 6 Register (MUXCTL6)

To Next Page

To Previous Page

I/O Configuration LH79524/LH79525 User’s Guide

11-12 Version 1.0

11.2.2.9 Multiplexing Control 6 Register (MUXCTL6)

The MUXCTL6 Register allows software to configure a number of LH79524/LH79525 pins.

Table 11-18. MUXCTL6 Register

BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

FIELD ///

RESET 0000000000000000

RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO

BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

FIELD /// PB1 PB0

RESET 0000000000000000

RW RO RO RO RO RO RO RO RO RO RO RO RO RW RW RW RW

ADDR 0xFFFE5000 + 0x28

Table 11-19. MUXCTL6 Fields

BIT NAME DESCRIPTION

31:4 /// Reserved Reading returns 0. Write the reset value.

3:2 PB1

PB1/DREQ/nUARTRTS0 Assignment

00 = PB1

01 = DREQ

10 = nUARTRTS0

11 = Reserved

1:0 PB0

PB0/nDACK/nUARTCTS0 Assignment

00 = PB0

01 = nDACK

10 = nUARTCTS0

11 = Reserved
