Reset, Clock, and Power Controller LH79524/LH79525 User’s Guide

13-12 Version 1.0

Figure 13-4. Remap = 0b01

Figure 13-5. Remap = 0b10

LH79525-1

ADVANCED HIGH-PERFORMANCE BUS

PERIPHERALS

ADVANCED PERIPHERAL BUS

PERIPHERALS

RESERVED

EXTERNAL SDRAM nDCS0

REMAP = 01

EXTERNAL STATIC MEMORY

EXTERNAL SDRAM

16KB INTERNAL SRAM

BOOT ROM

RESERVED

0xFFFFFFFF

0xFFFF1000

0xFFFF0000

0xFFFC0000

0xA0000000

0x80000000

0x60000000

0x40000000

0x20000000

0x00000000

LH79525-1

ADVANCED HIGH-PERFORMANCE BUS

PERIPHERALS

ADVANCED PERIPHERAL BUS

PERIPHERALS

RESERVED

INTERNAL SRAM

REMAP = 10

EXTERNAL STATIC MEMORY

EXTERNAL SDRAM

16KB INTERNAL SRAM

BOOT ROM

RESERVED

0xFFFFFFFF

0xFFFF1000

0xFFFF0000

0xFFFC0000

0xA0000000

0x80000000

0x60000000

0x40000000

0x20000000

0x00000000
