Sharp LH79524 - Software Interrupt Register (SOFTINT); Table 18-15. SOFTINT Register; Table 18-16. SOFTINT Fields

Vectored Interrupt Controller LH79524/LH79525 User’s Guide
18-10 Version 1.0
18.2.2.7 Software Interrupt Register (SOFTINT)
SoftInt is the Software Interrupt Register. This register generates software interrupts. Bits [31:0]
correspond to the interrupt number in Table 18-1. Note that interrupt number 1 is the only inter-
rupt souce not associated with a physical hardware interrrupt and is therefore reserved for soft-
ware interrupts. However, software interrupts can be generated using any of the 32 bit
locations in the SOFTINT register. For example, as software interrupt can be generated for
interrupt number 0 to test the interrupt processing of the hardware WDT interrupt.
Table 18-15. SOFTINT Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD SoftInt
RESET 0000000000000000
RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD SoftInt
RESET 0000000000000000
RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
ADDR 0xFFFFF000 + 0x018
Table 18-16. SOFTINT Fields
BITS NAME DESCRIPTION
31:0 SoftInt
Generate Software Interrupt Setting a bit generates a software interrupt for
the specific source interrupt before interrupt masking.
For each bit:
1 = Software Interrupt asserted
0 = Has no effect
