Ethernet MAC Controller LH79524/LH79525 User’s Guide
6-50 Version 1.0
6.3.4.3 Specific Address 1 Bottom (SPECAD1BOT)
This register contains the least-significant bits (bits [31:0]) of the destination address.
Bit zero indicates whether the address is multicast or unicast and corresponds to the least
significant bit of the first byte received
. SPECAD1 should be programmed with the system
MAC address.
6.3.4.4 Specific Address 1 Top (SPECAD1TOP)
This register contains the most-significant bits of the destination address (bits [47:32]).
Table 6-80. SPECAD1BOT Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD SPECAD1BOT
RESET 0000000000000000
TYPE RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD SPECAD1BOT
RESET 0000000000000000
TYPE RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
ADDR 0xFFFC7000 + 0x98
Table 6-81. SPECAD1BOT Fields
BITS NAME FUNCTION
31:0 SPECAD1BOT
Least Significant Destination Address Bits Least significant bits of
the destination address.
Table 6-82. SPECAD1TOP Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD ///
RESET 0000000000000000
TYPE RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD SPECAD1TOP
RESET 0000000000000000
TYPE RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
ADDR 0xFFFC7000 + 0x9C
Table 6-83. SPECAD1TOP Fields
BITS NAME FUNCTION
31:16 /// Reserved Reading returns 0. Write the reset value.
15:0 SPECAD1TOP
Most Significant Destination Address Bits The most significant bits
of the destination address, that is bits 47 to 32.
