LH79524/LH79525 User’s Guide Ethernet MAC Controller
Version 1.0 6-53
6.3.4.9 Specific Address 4 Bottom (SPECAD4BOT)
This register contains the least-significant bits of the destination address (bits [31:0]). Bit
zero indicates whether the address is multicast or unicast and corresponds to the least
significant bit of the first byte received
.
6.3.4.10 Specific Address 4 Top (SPECAD4TOP)
This register contains the most-significant bits of the destination address (bits [47:32]).
Table 6-92. SPECAD4BOT Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD SPECAD4BOT
RESET 0000000000000000
TYPE RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD SPECAD4BOT
RESET 0000000000000000
TYPE RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
ADDR 0xFFFC7000 + 0xB0
Table 6-93. SPECAD4BOT Fields
BITS NAME FUNCTION
31:0 SPECAD4BOT
Least Significant Destination Address Bits Least significant bits
of the destination address.
Table 6-94. SPECAD4TOP Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD ///
RESET 0000000000000000
TYPE RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD SPECAD4TOP
RESET 0000000000000000
TYPE RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
ADDR 0xFFFC7000 + 0xB4
Table 6-95. SPECAD4TOP Fields
BITS NAME FUNCTION
31:16 /// Reserved Reading returns 0. Write the reset value.
15:0 SPECAD4TOP
Most Significant Destination Address Bits The most significant
bits of the destination address, that is bits 47 to 32.
