LH79524/LH79525 User’s Guide Vectored Interrupt Controller
Version 1.0 18-13
18.2.2.11 Vector Address Registers (VECTADDRx)
There are 16 Vector Address Registers, designated VectAddr0 through VectAddr15. Each
register contains the ISR vector addresses for that particular vectored IRQ interrupt.
Table 18-23. VECTADDRx Registers
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD VICVectorAddr
RESET 0000000000000000
RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD VICVectorAddr
RESET 0000000000000000
RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
ADDR
VECTADDR0: 0xFFFFF000 +
0x100
VECTADDR1: 0xFFFFF000 + 0x104
VECTADDR2: 0xFFFFF000 + 0x108
VECTADDR3: 0xFFFFF000 + 0x10C
VECTADDR4: 0xFFFFF000 + 0x110
VECTADDR5: 0xFFFFF000 + 0x114
VECTADDR6: 0XFFFFF000 + 0x118
VECTADDR7: 0xFFFFF000 + 0x11C
VECTADDR8: 0xFFFFF000 + 0x120
VECTADDR9: 0xFFFFF000 + 0x124
VECTADDR10: 0xFFFFF000 + 0x128
VECTADDR11: 0xFFFFF000 + 0x12C
VECTADDR12: 0xFFFFF000 + 0x130
VECTADDR13: 0xFFFFF000 + 0x134
VECTADDR14: 0xFFFFF000 + 0x138
VECTADDR15: 0xFFFFF000 + 0x13C
Table 18-24. VECTADDRx Fields
BITS NAME DESCRIPTION
31:0 VectorAddr ISR Vector Addresses Contains ISR vector addresses.
