Sharp LH79524 - Software Reset Register (SOFTRESET); Table 13-10. SOFTRESET Register; Table 13-11. SOFTRESET Fields

Reset, Clock, and Power Controller LH79524/LH79525 User’s Guide
13-14 Version 1.0
13.2.2.4 Software Reset Register (SOFTRESET)
This register allows software to initiate a System Reset. To reset, software programs
0xDEAD into the lower 16 bits. SOFTRESET resets the entire chip, except the System PLL
and the USB PLL.
Table 13-10. SOFTRESET Register
BIT 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FIELD ///
RESET 0000000000000000
RW RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO RO
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FIELD SRST
RESET 0000000000000000
RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
ADDR 0xFFFE2000 + 0x0C
Table 13-11. SOFTRESET Fields
BITS NAME DESCRIPTION
31:16 /// Reserved Reading returns 0. Write the reset value.
15:0 SRST
Activate Software Reset Writing 0xDEAD (0b1101 1110 1010 1101) to this
field activates a System Reset. Do not write any other value to these bits.
