LH79524/LH79525 User’s Guide I/O Configuration

Version 1.0 11-47

5:4 PG4

Pin PG4/LCDVD2 Resistor Assignment

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved

3:2 PG3

Pin PG3/LCDVD1 Resistor Assignment

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved

1:0 PG2

Pin PG2/LCDVD0 Resistor Assignment

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved

Table 11-63. RESCTL22 Fields (Cont’d)

BIT NAME DESCRIPTION
