Direct Memory Access Controller LH79524/LH79525 User’s Guide
5-18 Version 1.0
7ERRORINT3
Data Stream 3 Error Interrupt Contains the status of the data stream 3
error interrupt.
1 = Error-interrupt asserted
0 = Error-interrupt not asserted
6ERRORINT2
Data Stream 2 Error Interrupt Contains the status of the data stream 2
error interrupt.
1 = Error-interrupt asserted
0 = Error-interrupt not asserted
5ERRORINT1
Data Stream 1 Error Interrupt Contains the status of the data stream 1
error interrupt.
1 = Error-interrupt asserted
0 = Error-interrupt not asserted
4ERRORINT0
Data Stream 0 Error Interrupt Contains the status of the data stream 0
error interrupt.
1 = Error-interrupt asserted
0 = Error-interrupt not asserted
3INT3
Data Stream 3 Interrupt Flag
1 = Interrupt Flag is active
0 = Interrupt Flag is not active
2INT2
Data Stream 2 Interrupt Flag
1 = Interrupt Flag is active
0 = Interrupt Flag is not active
1INT1
Data Stream 1 Interrupt Flag
1 = Interrupt Flag is active
0 = Interrupt Flag is not active
0INT0
Data Stream 0 Interrupt Flag
1 = Interrupt Flag is active
0 = Interrupt Flag is not active
Table 5-34. STATUS Fields (Cont’d)
BIT NAME DESCRIPTION
