LH79524/LH79525 User’s Guide Ethernet MAC Controller
Version 1.0 6-19
0x68 SENSERR Carrier sense errors
0x6C RXRERR Receive resource errors
0x70 RXOVERR Receive overrun errors
0x74 RXSYMERR Receive symbol errors
0x78 LENERR Excessive length errors
0x7C RXJAB Receive jabbers
0x80 UNDERFRM Undersize frames
0x84 SQERR SQE test errors
0x88 RXLEN Received length field mismatch
0x8C TXPAUSEFM Transmitted pause frames
MATCHING REGISTERS
0x90 HASHBOT Hash register bottom [31:0]
0x94 HASHTOP Hash register top [63:32]
0x98 SPECAD1BOT Specific address 1 bottom
0x9C SPECAD1TOP Specific address 1 top
0xA0 SPECAD2BOT Specific address 2 bottom
0xA4 SPECAD2TOP Specific address 2 top
0xA8 SPECAD3BOT Specific address 3 bottom
0xAC SPECAD3TOP Specific address 3 top
0xB0 SPECAD4BOT Specific address 4 bottom
0xB4 SPECAD4TOP Specific address 4 top
0xB8 IDCHK Type ID checking
0xC0 – 0xFC /// Reserved – Do not access
Table 6-5. EMAC Register Summary (Cont’d)
ADDRESS
OFFSET
NAME DESCRIPTION
