Ethernet MAC Controller LH79524/LH79525 User’s Guide
6-26 Version 1.0
4BUFEX
Buffers Exhausted Mid-Frame If the buffers run out of data during
transmission of a frame, transmission stops. When this happens, FCS is
bad and the Transmit Error (ETHERTXER) pin is asserted.
Read:
1 = Buffer exhausted mid-frame
0 = Normal operation
Write:
1 = Reset bit to 0
0 = No effect
3TXGO
Transmit Go Indicates that transmit is active.
Read:
1 = Transmit is active
0 = Transmit is not active
Write:
1 = Reset bit to 0
0 = No effect
2RETRYLIMIT
Retry Limit Exceeded Indicates that the transmission retry limit was
exceeded.
Read:
1 = Retry limit exceeded
0 = Normal operation
Write:
1 = Reset bit to 0
0 = No effect
1COLLISION
Collision Occurred Indicates that a collision occurred.
Read:
1 = Collision occurred
0 = Normal operation
Write:
1 = Reset bit to 0
0 = No effect
0 USEDBIT
Used Bit Read Indicates that a Transmit Buffer Descriptor is read with
its Used bit set.
Read:
1 = A transmit buffer description Used bit was set
0 = Normal operation
Write:
1 = Reset bit to 0
0 = No effect
Table 6-13. TXSTATUS Fields (Cont’d)
BITS NAME FUNCTION
