LH79524/LH79525 User’s Guide General Purpose Input/Output

Version 1.0 8-3

B12 PE0 LCDLP/LCDHRLP

D11 PE1 LCDDCLK

B13 PE2 LCDPS

C13 PE3 LCDCLS

D12 PE4 LCDDSPLEN/LCDREV

B16 PE5 LCDVDDEN

B15 PE6 LCDVEEN/LCDMOD

D14 PE7 nWAIT/nDEOT

A8 PF0 LCDVD6

A9 PF1 LCDVD7

B9 PF2 LCDVD8

C9 PF3 LCDVD9

B10 PF4 LCDVD10

A11 PF5 LCDVD11

B11 PF6 LCDEN/LCDSPL

A12 PF7 LCDFP/LCDSPS

A5 PG0 ETHERTXEN

B6 PG1 ETHERTXCLK

A6 PG2 LCDVD0

C7 PG3 LCDVD1

B7 PG4 LCDVD2

A7 PG5 LCDVD3

C8 PG6 LCDVD4

B8 PG7 LCDVD5

C4 PH0 ETHERRX3

A3 PH1 ETHERRXDV

B4 PH2 ETHERRXCLK

C5 PH3 ETHERTXER

D6 PH4 ETHERTX0

A4 PH5 ETHERTX1

B5 PH6 ETHERTX2

C6 PH7 ETHERTX3

D3 PI0 ETHERMDC

B1 PI1 ETHERMDIO

B2 PI2 ETHERCOL

D4 PI3 ETHERCRS

C3 PI4 ETHERRXER

A1 PI5 ETHERRX0

A2 PI6 ETHERRX1

B3 PI7 ETHERRX2

R16 PK0 D16

Table 8-2. LH79524 GPIO Multiplexing (Cont’d)

CABGA

NO.

AT RESET MULTIPLEXED FUNCTION(S)
