General Purpose Input/Output LH79524/LH79525 User’s Guide
8-6 Version 1.0
146 PF4 LCDVD10
145 PF5 LCDVD11
143 PF6 LCDEN/LCDSPL
142 PF7 LCDFP/LCDSPS
162 PG0 ETHERTXEN
161 PG1 ETHERTXCLK
159 PG2 LCDVD0
158 PG3 LCDVD1
157 PG4 LCDVD2
156 PG5 LCDVD3
155 PG6 LCDVD4
154 PG7 LCDVD5
171 PH0 ETHERRX3
170 PH1 ETHERRXDV
169 PH2 ETHERRXCLK
167 PH3 ETHERTXER
166 PH4 ETHERTX0
165 PH5 ETHERTX1
164 PH6 ETHERTX2
163 PH7 ETHERTX3
4 PI0 ETHERMDC
2 PI1 ETHERMDIO
1 PI2 ETHERCOL
176 PI3 ETHERCRS
175 PI4 ETHERRXER
174 PI5 ETHERRX0
173 PI6 ETHERRX1
172 PI7 ETHERRX2
20 AN3/LR/Y- PJ0
19 AN4/WIPER PJ1
18 AN9 PJ2
17 AN2/LL/Y+ PJ3
16 AN8 PJ4
15 AN5 PJ5/INT5
13 AN7 PJ6/INT6
12 AN6 PJ7/INT7
104 nCS0 PM0
103 nCS1 PM1
102 nCS2 PM2
100 nCS3 PM3
110 nBLE0 PM4
109 nBLE1 PM5
Table 8-3. LH79525 GPIO Multiplexing (Cont’d)
PIN AT RESET MULTIPLEXED FUNCTION
