LH79524/LH79525 User’s Guide I/O Configuration

Version 1.0 11-17

5:4 PC2

Pin PC2/A18 Resistor Assignment

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved

3:2 PC1

Pin PC1/A17 Resistor Assignment

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved

1:0 PC0

Pin PC0/A16 Resistor Assignment

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved

Table 11-25. RESCTL7 Fields (Cont’d)

BIT NAME DESCRIPTION
