LH79524/LH79525 User’s Guide I/O Configuration
Version 1.0 11-23
7:6 PD2
PD2/D10 Assignment
00 = PD2
01 = D10
10 = Reserved
11 = Reserved
5:4 PK2
PK2/D18 Assignment (LH79524 Only)
00 = PK2
01 = D18
10 = Reserved
11 = Reserved
3:2 PK1
PK1/D17 Assignment (LH79524 Only)
00 = PK1
01 = D17
10 = Reserved
11 = Reserved
1:0 PD1
PD1/D9 Assignment
00 = PD1
01 = D9
10 = Reserved
11 = Reserved
Table 11-31. MUXCTL11 Fields (Cont’d)
BIT NAME DESCRIPTION
