LH79524/LH79525 User’s Guide I/O Configuration

Version 1.0 11-25

5:4 PK2

Pin PK2/D18 Resistor Assignment (LH79524 Only)

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved

3:2 PK1

Pin PK1/D17 Resistor Assignment (LH79524 Only)

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved

1:0 PD1

Pin PD1/D9 Resistor Assignment

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved

Table 11-33. RESCTL11 Fields (Cont’d)

BIT NAME DESCRIPTION
